Outstanding accuracy of 0.015% of measured value + 0.01% of range
Full dynamic range of 500 µA to 32 A / 3 mV to 1000 V per channel available in single instrument
Power measurements from standby to full load (max. 32 A) without mechanical changes
Analog bandwidth DC up to 10 MHz
Modular configuration with 1 to 7 power measurement channels (alternatively 6 channels + 1 I/O card)
Gapless sampling up to 18 bit and a minimal cycle time of 10 ms
Delay time between V and I input < 3ns, very precise measurements at small power factors (PF) and/or high frequencies
Outstanding accuracy of 0.015% of measured value + 0.01% of range
Full dynamic range of 500 µA to 32 A / 3 mV to 1000 V per channel available in single instrument
Power measurements from standby to full load (max. 32 A) without mechanical changes
Analog bandwidth DC up to 10 MHz
Modular configuration with 1 to 4 power measurement channels (alternatively 3 channels + 1 I/O card)
Gapless sampling up to 18 bit and a cycle time of 30 ms
Delay time between V and I input < 3ns, very precise measurements at small power factors (PF) and/or high frequencies
Outstanding accuracy of 0.015% of measured value + 0.01% of range
Full dynamic range of 500 µA to 32 A / 3 mV to 1000 V per channel available in single instrument
Power measurements from standby to full load (max. 32 A) without mechanical changes
Analog bandwidth DC up to 10 MHz
Gapless sampling up to 18 bit and a minimal cycle time of 30 ms
Delay time between V and I input < 3ns, very precise measurements at small power factors (PF) and/or high frequencies
